Residual Analyzers
Series CL7615 Chlorine Residual Analyzers
- Continuous on-line operation.
- High-reliability.
- Multiple ranges – up to 5 PPM.
- High & low Alarm variable set points.
- Direct display of free Chlorine.
The CL7615 Residual Chlorine Analyzer has been independently tested and proven to be a reliable analyzer for continuous, accurate residual analysis.A potentiostatic-based instrument is designed to continuously analyze free chlorine in water, wastewater, cooling water and other process water applications.It features a factory set monitoring ranges from 0-1 to 0-5 PPM. The analyzer has an inbuilt temperature compensation mechanism, thereby providing consistent residual values.CL7615 is constructed of corrosion-resistant materials Each unit is factory tested and requires no field wiring.
DESIGN FEATURES
- No Reagents: Because the applications have a relatively stable pH, the accuracy and reliability can be maintained at 5% of full scale the need of costly reagents.
- High & Low alarm Set points: Monitor and control free chlorine within a concentration band with high and low alarm set points that are easily adjusted on the front panel. LED lights indicate and alarm has occurred.
- Easy Mounting: The Series CL 7615 Residual Chlorine Analyzer is supplied with mounting enclosure with mounting holes to install exactly into place.
- Accuracy: The 5% accuracy of the unit is ideal for the monitoring and control of most clean water samples.
APPLICATIONS
- Water Disinfection: Drinking water requires continuous monitoring of chlorine residuals.
- Swimming Pool Disinfection: Require low cost accurate monitoring of free chlorine.
- Cooling Water Biofouling: Cost effective control of slime and algae in piping, heat exchangers and cooling towers by monitoring free chlorine.
- Industrial Process Water: Accurate monitoring of residual chlorine in industrial process waters.
